The SureColor® P8570DL is a next-generation wide-format printer engineered to deliver incredible photo production speeds, premium image quality, and exceptional productivity. Designed for professional workflows, this 44″ printer features dual-roll capability, high-capacity 1.6 L ink packs, and PrecisionCore® MicroTFP technology for consistent, vibrant output.

Key Features

• Unmatched Performance: Print speeds up to 195 ft²/hr for photographic media and 1,571 ft²/hr for plain paper in draft mode.
• PrecisionCore MicroTFP Printhead: 9,600 nozzles for stunning detail with droplet sizes as small as 3.5 picoliters.
• UltraChrome® PRO6 Inks: Six-color pigment ink set includes Gray for exceptional gradients and black-and-white performance comparable to 8-color printers.
• Dual-Roll Capability: Seamless media switching or roll-to-roll production with built-in take-up reel.
• Front-Load Design: Compact flattop design with full front operation for easy media access and loading.
• 4.3″ Touchscreen Panel: Configurable and user-friendly interface with onboard diagnostics and maintenance automation.
• Integrated Adobe® Embedded Print Engine: Native processing for PDF and PostScript files for faster workflows.
• Wi-Fi & Network Ready: SuperSpeed USB 3.0, 1000BASE-T Ethernet, and 802.11ac Wi-Fi support included.
• Security Suite: Over 28 security features including hardware encryption, user tracking, and IC card control options.
• No Assembly Needed: Ready to print in as little as 30 minutes.

Technical Specifications

Print Technology

• PrecisionCore MicroTFP 6-channel drop-on-demand printhead
• Max Resolution: 2400 x 1200 dpi
• Black Ink Switching: Automatic switching between Photo and Matte Black
• Print Languages: Epson ESC/P®, Adobe PostScript 3™, Adobe PDF 1.7

Print Speeds (per media type)

• Premium Glossy Photo Paper: Up to 361 ft²/hr (Draft), 195 ft²/hr (Quality)
• Plain Paper: Up to 1,571 ft²/hr (Draft), 1,200 ft²/hr (Speed), 213 ft²/hr (High Quality)

Ink System

• UltraChrome PRO6 pigment ink
• 6 Colors: Cyan, Magenta, Yellow, Matte Black, Photo Black, Gray
• 1.6 L ink pack per color (sold separately)

Media Handling

• Dual Front-Loading Rolls: 10″ to 44″ width
• Roll Diameter: Up to 6.69″, Weight: Up to 27 lb
• Media Thickness: 0.07 mm – 0.8 mm (roll & sheet), 0.8 mm – 1.5 mm (posterboard)
• Cutting: High-speed rotary cutter (manual or auto)
• BorderFree® Sizes: Includes 10″, 13″, 16″, 17″, 20″, 24″, 36″, 44″, and more

Control Panel & Interfaces

• 4.3″ Articulating Touchscreen Display
• Interfaces: USB 3.0, Ethernet 100BASE-TX / 1000BASE-T, Wi-Fi (2.4 & 5 GHz), USB memory stick

OS Compatibility

• Windows XP to Windows 10 (32/64-bit)
• Windows Server 2003 – 2019
• Mac OS X 10.9.5 and later, macOS 11+

Physical & Electrical

• Dimensions (operational): 73″ W x 32.6″ D x 38.4″ H
• Weight: 364 lb
• Operating Noise: 49.6 dBA
• Power Use: 70 W (Printing), 32 W (Ready), 2 W (Sleep), 0.3 W (Standby)
• Voltage: 110V – 240V | Frequency: 50 – 60 Hz

Eco Features

• ENERGY STAR® certified
• RoHS compliant
• Recyclable design
• SmartWay® Transport Partner

What’s in the Box

• SureColor P8570DL Printer with Adobe Embedded Print Engine
• 2 Roll Media Adapters (installed)
• Maintenance Boxes (pre-installed)
• Start Here Setup Poster
• AC Power Cable
• Note: Ink and media sold separately

Available Accessories

• Replacement Cutter Blade (C13S210117)
• Additional Roll Feed Spindle – 44″ (C12C936171)
• Maintenance Box (C13S210115)
• Borderless Maintenance Box (C13S210116)
• Cleaning Stick (C13S090013)
• 960GB SSD Memory Unit (C12C936671)
• Production Stacker – 44″ Wide (C12C937131)

UltraChrome PRO6 Ink Packs (1.6 L each)

• Photo Black: T53E120
• Cyan: T53E220
• Magenta: T53E320
• Yellow: T53E420
• Gray: T53E720
• Matte Black: T53E820
• Starter Pack Set: T53EM20

What’s in the box:

• SureColor P8570DL Printer with Adobe Embedded Print Engine
• 2 Roll Media Adapters Installed
• Maintenance Boxes (Preinstalled)
• Start Here Poster
• AC Power Cable

Note: Ink and Media are not included with the printer.
